Description
|
Model
|
51.2V314AH
|
||
|
Nominal Voltage
|
51.2V
|
||
|
Nominal Capacity
|
314AH
|
||
|
Dimension moudle(mm)
|
483*245*792mm
|
||
|
Weight(kg)
|
114kg
|
||
|
SPECIFICATIONS
|
PARAMETER
|
||
|
Nominal Voltage (V)
|
51.2
|
||
|
Nominal Capacity (kWh)
|
16.1
|
||
|
Discharge Voltage (V)
|
44.8
|
||
|
Charge Voltage (V)
|
56.8
|
||
|
Recommend Charge/Discharge Current (A)
|
100
|
||
|
Max.Charge/Discharge Current(A)
|
200
|
||
|
Communication
|
RS485/RS232/CAN
|
||
|
Working Temperature |
0℃~50℃ Charge
|
||
|
-10℃~50℃ Disharge
|
|||
|
Transport or Storage Temperature Range
|
-20℃~60℃
|
||
|
Certification
|
CE/IEC/UL/UN38.3/MSDS
|
||
|
Design Life
|
15years+
|
||
|
Cycle Life
|
(0.5C/0.5C-80%DOD)>6000 times
|
||
|
Parallel Function
|
Support 15 units in Parallel
|
||
|
Certification
|
UN38.3/MSDS/ROHS
|
||
